LNG ISO Container

Name: High Quality 40 Ft LNG ISO Container Capacity For Sale In China
Availability: InStock
Rating: 4.5 (89 reviews)

LNG iso tank container constitute one type of CIMC ENRIC's standardized, modularized and light-weight transport equipment, and having inherited the feature of transport convenience of containers and integrated the profound storage and transport-related technologies of CIMC ENRIC, they can be used for multimodal transport (marine, railway and road transport ) and for the large-quantity storage and transport of cryogenic liquid. By virtue of their standardized and modularized design, LNG iso tank containers can organically combine with upstream and downstream LNG application facilities and perfectly blend into the overall solution for application as the storage and transport link, thus creating higher values for clients.

Contact Now

download

DESCRIPTION

Features:

LNG ISO container products strictly adhere to international standards and specifications including CSC, IMDG, ISO, CUSTOMS, ADR, RID, U.S. DOT, and ASME VIII-1. By implementing uniform technical design, quality control, and process manufacturing standards, this series of tank containers enables multimodal transportation globally, providing a one-stop, flexible, and convenient solution for diverse logistics scenarios.

Technical Specification:

40ft Cryogenic Tank Container
DAG.NO	Design Code	MAWP(MPa)	Capacity(m³)	Tare Weight(kg)	Load weight(kg)	Rated weight(kg)
CGBIS-40-0.79	GB	0.79	45.5m³	11580	18900	30480
CASIS-40-0.83	ASME	0.83	45.5m³	11580	18900	30480
CASIS-40-0.79/0.83	GB/ASME	0.79/0.83MPa	45.5m³	11580	18900	30480
CASIS-40-0.483	ASME	0.483(70psi)	45m³	10250	23750	34000
CASIS-40-0.758	ASME	0.758(110psi)	45.5m³	11580	22420	34000

20ft Cryogenic Tank Container (Side Opening door)
DAG.NO	Design Code	MAWP(MPa)	Capacity(m³)	Tare Weight(kg)	Load weight(kg)	Rated weight(kg)
CASIS-20-1.6-S	ASME	1.6	21.1m³	7500	28500	36000
CASIS-20-1.8-S	ASME	1.8	21.1m³	7800	28200	36000
CASIS-20-2.4-S	ASME	2.4	21.1m³	8800	27200	36000
CENIS-20-1.8-S	EN	1.8	21.4m³	8600	27400	36000
CENIS-20-2.4-S	EN	2.4	21.1m³	10000	26000	36000

20ft Cryogenic Tank Container (Back Opening door)
DAG.NO	Design Code	MAWP(MPa)	Capacity(m³)	Tare Weight(kg)	Load weight(kg)	Rated weight(kg)
CASIS-20-1.6-B	ASME	1.6	20.2m³	7200	28800	36000
CASIS-20-1.8-B	ASME	1.8	20.2m³	7550	28450	36000
CASIS-20-2.4-B	ASME	2.4	20.2m³	8400	27600	36000
CASIS-20-3.5-B	ASME	3.5	20.2m³	10250	25750	36000

LNG ISO Container
Water Volume(M3)	Working Pressure(Bar)	Tare Weight(Kg)	Total Weight(Kg)
45.5(Customized as users demands)	8.3	11580	30480
21.13(Customized as users demands)	7.5	7160	16090
